Electromechanical slim relay, 48 Vdc,...

Electromechanical slim relay, 48 Vdc, SPDT, 6 A, through-hole (THT), 34.51 series - Finder 34.51.7.048.0010

Electromechanical slim relay, 48 Vdc, SPDT, 6 A, through-hole (THT), 34.51 series - Finder 34.51.7.048.0010

Name: Electromechanical slim relay, 48 Vdc, SPDT, 6 A, through-hole (THT), 34.51 series - Finder 34.51.7.048.0010
Brand: Finder
SKU: 52.130.6004001
Price: 10.7 EUR
Availability: OutOfStock

SKU 52.130.6004001

Out-of-Stock

€10.70

Tax included

Ultra-slim electromechanical relay for printed circuit board, 1 contact 6 A and low-consumption coil.

Features:
- 1 changeover contact;
- Ultra thin, 5 mm wide;
- Low power consumption coil - 170 mW;
- UL Listing (relay/coil combination);
- 6 kV (1.2/50 μs) insulation between coil and contacts;
- PCB mounting or Finder 93 series sockets;
- AgNi contacts.

Quantity	Unit price	You Save
10	€10.17	€5.35

Description

Contact configuration
Contact configuration	1 exchange
Rated current/maximum instantaneous current	6A / 10A
Rated voltage / maximum switchable voltage	250Vac / 400Vac
Nominal load in AC1	1500VA
Nominal load in AC15	300VA
Minimum switchable load	500mW
Contact material	AgNi
Coil characteristics
Nominal supply voltage	48Vdc
Nominal power	0,17W
General features
Mechanical durability	10 x 10⁶ cycles
Electrical durability	60 x 10³ cycles
Switching time: excitation/de-energization	5ms / 3ms
Insulation between coil and contacts	6KV
Dielectric strength between open contacts	1000Vac
Operating temperature	-40°C ~ +85°C
Protection category	RTII
Product information
Model	34.51.7.048.0010
Manufacturer	Finder
