Fuse NH 2, delayed tripping, 500V 200A, use gG - Wimex 5502200

Fuse NH 2, delayed tripping, 500V 200A, use gG - Wimex 5502200

Name: Fuse NH 2, delayed tripping, 500V 200A, use gG - Wimex 5502200
Brand: Wimex
SKU: 61.001.2205301
Price: 12.7 EUR
Availability: OutOfStock

SKU 61.001.2205301

Out-of-Stock

€12.70

Tax included

NH fuses are suitable for overload and short-circuit protection of lines, motors, transformers, i.e. for industrial applications.
Compliant with standards: IEC 32.1-.4, VDE 0636, IEC EN 60269.1-.2, DIN 43620.

Description

Rated voltage	500 Vac
Interrupting power (lk)	120 KA
Rated frequency	50 Hz
Frequency of operation	45 ~ 62 Hz
Class of use	gG (gL VDE)
Insulator material	Steatite
Conductor material	Silver-plated copper
Melting indicator	Fuse top with steel spring
Maximum operating temperature	80°C
Mechanical resistance	Vibration: 7 ~ 50 Hz with 1g
	Impacts: 5g
Characteristic intervention	Delayed
Reference Standards	CEI 32.1-.4, VDE 0636, IEC EN 60269.1-.2, DIN 43620
Model	5502200
Manufacturer	Wimex
