Fuse NH 3, 690V 315A, use aM - Wimex 5509315
Fuse NH 3, 690V 315A, use aM - Wimex 5509315

Fuse NH 3, 690V 315A, use aM - Wimex 5509315

61.001.2205505
Out-of-Stock
€36.90
Tax included
NH fuses with the operating class aM are especially used for motor protection and, unlike the gG types, are only capable of interrupting currents between a certain overcurrent value (Kln) and the value corresponding to its breaking capacity.

Description

Rated voltage690 Vac
Interrupting power (lk)80 KA
Rated frequency50 Hz
Frequency of operation45 ~ 62 Hz
Class of useaM
Insulator materialSteatite
Conductor materialSilver-plated copper
Melting indicatorFuse top with steel spring
Maximum operating temperature80°C
Mechanical resistanceVibration: 7 ~ 50 Hz with 1g

Impacts: 5g
Characteristic interventionStarting engines
Reference StandardsCEI 32.1-.4, VDE 0636, IEC EN 60269.1-.2, DIN 43620
Model5509315
ManufacturerWimex

Product Details

Brand
Wimex
Fuse type
NH3 - motor protection
Rated voltage
690V
Corrente nominale
315 A
