Fuse NH 3 M68 aR 170 series, super fast, with striker, 690V 630A - Wimex 5523810

Fuse NH 3 M68 aR 170 series, super fast, with striker, 690V 630A - Wimex 5523810

Name: Fuse NH 3 M68 aR 170 series, super fast, with striker, 690V 630A - Wimex 5523810
Brand: Wimex
SKU: 61.001.2205916
Price: 219.1 EUR
Availability: OutOfStock

SKU 61.001.2205916

Out-of-Stock

€219.10

Tax included

NH super-rapid industrial fuses, characterised by high breaking capacity and low specific energy throughput (I²t), are manufactured with blade and bolt fixing, both with aR (short-circuit protection) and gR (full short-circuit and overload protection) characteristics.
Reference standards: IEC 32.1-.7,IEC EN 60269.1-.4, DIN 43620, VDE 0636.

Description

Rated voltage	690 Vac (IEC); 700 Vac (UL)
Interrupting power (lk)	690 Vac 200 KA (IEC); 700Vac 200 KA (UL)
Material	Steatite
Intervention characteristic	Super fast
Interruption range	AR
I²t	220000
Pw	45
Reference Standards	CEI 32.1-.7,IEC EN 60269.1-.4, DIN 43653
Model	5523810
Manufacturer	Wimex
