| Contact characteristics | |
| Number of contacts | 2, NO |
| Rated current/maximum instantaneous current | 10A / 20A |
| Rated voltage / maximum switchable voltage | 250Vac / 400Vac |
| Nominal load in AC1 | 2500VA |
| Nominal load in AC15 | 500VA |
| Lamp range | Incandescent, halogen: 800W |
| Fluorescents: 400W | |
| CFL: 200W | |
| Led: 200W | |
| Halogen with electronic transformer: 200W | |
| Halogen with electromagnetic transformer: 400W | |
| Minimum switchable load | 1000mW |
| Contact material | AgNi |
| Coil characteristics | |
| Nominal supply voltage | 230Vac |
| Nominal power | 4.5VA |
| General features | |
| Mechanical durability | 300 x 10³ cycles |
| Electrical durability | 100 x 10³ cycles |
| Command pulse duration | 0.1 uS |
| Insulation between coil and contacts | 4KV |
| Coil characteristics | |
| Rated voltage | 230V |
| Operating range | 184Vac - 253Vac |
| Resistance | 6250 ohm |
| Absorption | 20 mA |
| Product Information | |
| Model | 26.04.8.230.0000 |
| Manufacturer | Finder |
