Relay, 5 Vdc, SPDT, 10 A, through-hole (THT), 36.11 series - Finder 36.11.9.005.4011
Relay, 5 Vdc, SPDT, 10 A, through-hole (THT), 36.11 series - Finder 36.11.9.005.4011
Relay, 5 Vdc, SPDT, 10 A, through-hole (THT), 36.11 series - Finder 36.11.9.005.4011

Relay, 5 Vdc, SPDT, 10 A, through-hole (THT), 36.11 series - Finder 36.11.9.005.4011

52.130.1002002
20 Items
€3.12
VAT included
Mini relay for printed circuit board, 1 changeover 10A.

Features:
- Small size;
- 1 changeover contact;
- Sensitive DC coil - 360 mW;
- Washable: RT III;
- Cadmium-free contacts.

Quantity Unit price You Save
10 €2.81 €3.12

Description

Contact configuration
Contact configuration1 exchange
Rated current/maximum instantaneous current10/15 (NO); 5/10 (NC)
Rated voltage / maximum switchable voltage250Vac / 277Vac
Nominal load in AC12500 (NO); 1250 (NC)
Nominal load in AC15500 VA (NO)
Minimum switchable load500 mW
Contact materialAgSnO2
Coil characteristics
Nominal supply voltage5Vdc
Nominal power0,36W
General features
Mechanical durability10 x 10⁶ cycles
Electrical durability50 x 10³ cycles
Switching time: excitation/de-energization10ms / 5ms
Insulation between coil and contacts4KV
Dielectric strength between open contacts750Vac
Operating temperature-40°C ~ +85°C
Protection categoryRTIII
Product information
Model36.11.9.005.4011
ManufacturerFinder

Product Details

Brand
Finder
Relay type
Power relays
Contact configuration
SPDT
Coil voltage
5 Vdc
Contact current
10A
