Fuse NH 000, 500V 10A, use aM - Wimex 5505010
Fuse NH 000, 500V 10A, use aM - Wimex 5505010

Fuse NH 000, 500V 10A, use aM - Wimex 5505010

61.001.2203503
Out-of-Stock
€5.80
VAT included
NH fuses with the operating class aM are especially used for motor protection and, unlike the gG types, are only capable of interrupting currents between a certain overcurrent value (Kln) and the value corresponding to its breaking capacity.

Description

Rated voltage500 Vac
Interrupting power (lk)120 KA
Rated frequency50 Hz
Frequency of operation45 ~ 62 Hz
Class of useaM
Insulator materialSteatite
Conductor materialSilver-plated copper
Melting indicatorFuse top with steel spring
Maximum operating temperature80°C
Mechanical resistanceVibration: 7 ~ 50 Hz with 1g

Impacts: 5g
Characteristic interventionStarting engines
Reference StandardsCEI 32.1-.4, VDE 0636, IEC EN 60269.1-.2, DIN 43620
Model5505010
ManufacturerWimex

Product Details

Brand
Wimex
Fuse type
NH000 - motor protection
Rated voltage
500V
Corrente nominale
10 A
